Dont just buy replacement suspension parts for your Dodge Ram 1500 4wd 2001, buy the absolutely BEST Dodge Ram 1500 4wd 2001 suspension parts. At EnergySuspensionParts.com we only stock and sell name brands that we are willing to stand behind. You can find the best suspension parts for your Dodge Ram 1500 4wd 2001 at the best prices at EnergySuspensionParts.com. So whether you need to replace your worn and sagging suspension bushings with performance replacements, or you are upgrading your OE suspension with larger sway bars and sway bar bushings - EnergySuspensionParts.com is where you'll find them.
Ball Joints and Ball Joint Parts | Dodge Ram 1500 4wd 2001
The two different colors are essentially the same at a formula level. Some black components are graphite impregnated as a self-lubricating agent, but overall they are the same part. Graphite is not added to the red formula simply because it changes the color of the bushing.
Bushing hardness by color?
The Durometer (or hardness) of red and black bushings are the same for that position. The different colors do not indicate a higher or lower durometer.
Why buy red bushings?
Red or black bushings is almost entirely an aesthetic choice, there is no real functional difference between the two. Some who drive their vehicles especially hard (track, rally, etc.) sometimes use red bushings because it is easier to see any damage that the bushing might have suffered from extreme conditions.
Are there other bushing colors?
Energy Suspension used to have Yellow and Blue options but they stopped producing components in these colors a long time ago and they are no longer available on the market.
Special Order Terms
Special Order Details
"Prothane"
This part is not stocked at any of our warehouses. However we
can have the part shipped directly to you from the manufacturer Prothane.
Special Order Fees:
We will pay all special order fees. Purchasing a special order part will
not cost you any more than if we had stocked it.
Domestic Orders:
For all orders shipping to the United States - the part will ship
directly to you from the manufacturer. If you've purchased other parts
along with a special order part, we will send them all in one single
shipment.
International Orders:
For all orders shipping outside the United States, this part will be
shipped directly to our forwarding office. We will fill out the necessary
paperwork and forward the part on to you via your selected shipping option.
If you've purchased other non special order parts - your entire order will
wait to ship until this part has arrived.
Returns
Special Order parts do not qualify for returns. If you purchase a
special order part we will not be able to assist you with a return. If your
special order part is damaged, or missing a piece we will assist you in
promptly receiving the correct order.
Color
Prothane Red vs Black
Black, or Red? Red, or Black?
Prothane makes bushings in both colors. But is there a difference in them? Is one harder than the other? There are a lot of misconceptions about the color difference in Prothane's bushings, so let us at DST clear that up for you.
How are these two colors different?
Aside from the actual color, there isn't really a difference at all between the red and the black. They are the same durometer, or hardness, so they will perform the same and both should last the life of your vehicle.
What about the graphite rumor?
The black bushings do have a small amount of graphite mixed in with the polyurethane which has the potential to help with squeaking. But really, the best way to prevent Prothane bushings from squeaking is to use the supplied pre-lube* and grease them properly at install. So whether you choose the red, or the black, just be sure to grease them properly to avoid any squeaking.
* Some types of bushings only compress, such as body mounts and endlinks, and do not come with grease because they do not need grease. So if your kit comes with grease, be sure to use it!
Made in Black Only
Unlike nearly every other Energy Suspension brand part. This part is only produced in Black. Inquiries concerning this revealed that at the time they do not plan to make this part in Red now or in the future.
Front Sway Bar Bushings
Why are there so many different sway bar bushing sizes for my
application?
Much to the dismay of many buyers - almost all automotive manufacturer's
used several different size sway bars in their vehicles. There is no rhyme
or reason to this practice. It is random and different between cars of the
same make, model, year etc. The ONLY way to ensure you're buying the
correct size bushings for your car is to actually physically measure the
sway bar. The is most commonly done one of two ways.
1 - Wrench method. This is quite simple - just take a set of
wrenches and see which one fits over the bar correctly. For example -
if a 18mm wrench fits perfectly over your sway bar - then you have an
18mm sway bar! Not all of us are lucky enough to be able to us this
method as there are at times mid-sizes like 23.5mm etc. See below if
you fall into this category.
2 - Crescent Wrench Method. Just a little more complex than the
wrench method. Simply tighten down your adjustable crescent wrench down
over your sway bar. When it's tight - slip the wrench off and measure
between the ends of the prongs. The distance between these is the size
of your sway bar.
Alternate - Energy Suspension's sway bar measuring tape tool. You
will need to ensure you print this out at exact 1 - 1 dimensions. For
that reason alone - we strongly suggest using method 1 or 2. You can
find the tape tool here on Energy Suspension's website:
Buying the correct size bushings is VITAL to ensuring optimum
performance from your sway bar. Bushings that are too large will not
properly grip and support the sway bar. Likewise bushings that are too
small may simply not fit over the bar and make installation impossible.
If you cannot find the correct size sway bar bushings listed under your
vehicle's specific category - take a look at the
Universal Sway Bar Bushings Page.
Body Mount Bushings
Rear Leaf Spring Bushings
Front Track Bar Bushings - 1500 ONLY
Octagon Style Boots
Energy Suspension Makes 2 versions of dust boots in this size. The -Round- version is by far the most common. The -Octagon- version is simply a slightly different shape on the outside offering a faceted Octagon shape instead of the smooth round shape. Both versions of these dust boots work the exact same, some people just like the appearance of one version over the other.
Round Style
Octagon Style
Wide Spring Kit
There are 2 size leaf springs in these trucks. Most of them have 2.5 inch wide springs. Some however will have 3 inch wide springs. These wider springs will require a different set of rear leaf spring bushings. If you select the 3 Inch wide springs version, we will swap the standard 2.5 inch wide bushings for the larger 3 inch wide.
The WIDTH refers to the width of the spring itself. Always measure the SPRING when trying to determine which set you need. Dont measure the bushings. (explanation follows for those of you who want the details on WHY) The overall width of the bushings in a 2.5 inch wide spring would actually be about 3 inches and the overall width of the bushings in a 3.0 Inch wide spring would be about 3.5 inches. This is because there is about 1/4 inch of bushing flange on either side of the bushings.
Club or Quad Cab with Long Bed?
Free Lifetime Warranty Upgrade
Putting the Icing on the Cake
Energy Suspension offers a 7 year warranty for every part they make. But we know the quality of these parts deserves the peace of mind that a Lifetime Warranty provides. Exclusively for DST customers, we offer a FREE upgrade to a Lifetime Warranty handled directly thru us. No strings, no hassles, no receipts needed.
